Brake Cups
- 1. EPDM brake cups designed to work seamlessly with brake caliper seal systems.
- 2. High compression resilience ensures stable sealing under high pressure.
- 3. Compatible with DOT brake fluids to maintain system integrity.
- 4. Excellent aging resistance ensures long-term performance.
- 5. Precision molded for consistent fit and reliability.
PRODUCT - Brake Cups
| HOBA No. | A | B | Nom |
| 05302001 | 16.95 | 5.5 | 11/16 |
| 06302001 | 18.5 | 5.85 | 3/4 |
| 08302001 | 21.7 | 7 | 7/8 |
| 09302001 | 22.88 | 7.03 | 15/16 |
| 10302001 | 25.06 | 7.05 | 1 |
| 12302001 | 28.03 | 7.44 | 1 1/8 |
| 53600301 | 23 | 6.8 | 15/16 |
| 58904701 | 21 | 7.11 | 7/8 |
| 61204701 | 16.3 | 6 | 11/16 |
| 62204701 | 19.9 | 7 | 13/16 |
| 62404701 | 18.15 | 6.2 | 3/4 |
| HOBA No. | A | B | Nom |
| 00304006 | 30.6 | 8.55 | 1 1/4 |
| 44600001 | 19.9 | 6.5 | 13/16 |
| 45304001 | 14.85 | 6.3 | 5/8 |
| 46304101 | 20.95 | 7 | 7/8 |
| 54604701 | 21.25 | 7 | 7/8 |
| 60104701 | 24 | 7.5 | 1 |
| HOBA No. | A | B | Nom |
| 00400302 | 21.4 | 8 | 7/8 |
| 00700302 | 28.2 | 8 | 1 1/8 |
| 01104421 | 43.35 | 10.5 | 1 3/4 |
| 01210001 | 14.9 | 6 | 5/8 |
| 02300301 | 21.8 | 7 | 7/8 |
| 02500102 | 17.59 | 4.5 | 3/4 |
| 15800401 | 18.48 | 7 | 3/4 |
| 20A00101 | 16.5 | 6 | 11/16 |
| 30002220 | 21.68 | 8 | 7/8 |
| 30004120 | 40.1 | 9.45 | 1 5/8 |
| 30004620 | 45.23 | 10 | 1 27/32 |
| 30005020 | 49.23 | 10.5 | 2 |
| 49900101 | 24.85 | 7.5 | 1 |
| 53400301 | 20.03 | 6.55 | 13/16 |
| 53500301 | 23.3 | 7 | 15/16 |
| 59900101 | 28.25 | 7 | 1 1/8 |
| 71902421 | 36.75 | 10.6 | 1 1/2 |
| HOBA No. | A | B | Nom |
| 00003120 | 30.22 | 11 | 1 1/4 |
| 00003820 | 36.3 | 11 | 1 1/2 |
| 00302004 | 18 | 6.1 | 3/4 |
| 10810201 | 23.5 | 9 | 1 |
| 27318001 | 21.15 | 6.95 | 7/8 |
| HOBA No. | A | B | Nom |
| 51310701 | 21.49 | 8 | 7/8 |
| HOBA No. | A | B | Nom |
| 20112001 | 14.75 | 5 | 5/8 |
| HOBA No. | A | B | Nom |
| 63200701 | 50.4 | 11.25 | 2 |
| 63600701 | 34.5 | 7.62 | 1 3/8 |
| HOBA No. | A | B | Nom |
| 03305101 | 36.15 | 9 | 1 7/16 |
| 42303001 | 34.45 | 8.6 | 1 3/8 |
| HOBA No. | A | B | Nom |
| 28305001 | 46.5 | 11 | 47.5 |
| 63100701 | 54.95 | 12 | 55.56 |
| 63300701 | 47.1 | 10.38 | 1 7/8 |
| 63400701 | 44.1 | 9.99 | 1 3/4 |
| 63800701 | 36.15 | 8 | 1 7/16 |
| HOBA No. | A | B | Nom |
| 04000302 | 28.65 | 7.5 | 1 1/8 |
